Product Introduction
Fully isolated dual channel, capable of simultaneously outputting and measuring voltage, current, resistance, frequency, TC, and RTD, providing independent 24V DC power supply. Cooperate with the JY7000 digital pressure module to complete pressure calibration and precision measurement.
Calibration equipment
Ordinary temperature and pressure transmitters, thermocouples and thermal resistance thermometers, data recorders, tachometers, vortex flow meters, pressure gauges, pressure switches, JY824 supports HART intelligent temperature and pressure transmitters, etc.
Main Features
The output port can withstand 36V DC input error, and the measurement port can withstand 250V AC input error;
Received the invention patent "CNC variable resistance device", with faster and more stable response rate of resistor output;
24V DC power supply with high load current of 80mA;
A powerful intelligent management software that automatically and efficiently collects and reports calibration data, making the calibration process easier.
Selection reference
